Type
Inkjet Label Printer
Print Method
Pigment-based Inkjet
Ink Cartridges
4 (1 x Black, 1 x Cyan, 1 x Magenta, 1 x Yellow)
Print Resolution
1200 x 1200 dpi
Number of Nozzles
Magenta/Black/Yellow/Cyan: 2,560
First Print Out Time
13.6 sec or less
Default Print Speed
Matte Coated: Standard 14.0 mm/sec, Fine 7.3 mm/sec, Fast 26.1 mm/sec
Print Speed Range
7.3 – 47.0 mm/s
Supported Media Types
Label Roll Media (with Roll Holder), Fanfold Media (IJ Coated: Matte or Glossy)
Supported Media Format
Label Roll Media (with Roll Holder), Fanfold Media
Roll Media Capacity
Outer Diameter: Up to 6.0 inch (152.4mm), Core/Inner Diameter: 3.0 inch ± 0.04inch (76.2±1.0mm)
Fanfold Media Capacity
Media Height: Up to 11.8 inch (300mm)
Media Size – Width
2.0 – 8.5 inch (50.9 – 216.0 mm) Including Liner
Media Size – Length
1.5 – 53.0 inch (38.1 – 1,346.20 mm)
Media Thickness
5.0mil-8.5mil (0.1-0.2mm)
Max. Printable Area Width
Up to 8.61 inch (215.9mm)
Max. Printable Area Length
Up to 53.62 inch (1343.2mm)
Min. Margin Top/Bottom
118.1mil (0.12 inch) (3.0 mm)
Min. Margin Left/Right
59.1mil (0.06 inch) (1.5 mm)
Product Life
2.3 Million Sheets or 5 Years
Ink Cartridge Fill Volume
Black / Cyan / Magenta / Yellow: 10.1oz (300 ml)
Maintenance Cartridge Info & Fill Volume
WT-X801 Maintenance Cartridge : 12.2oz (360 ml), Approx. 49,000 Sheets
Control Panel
4.3-inch LCD touch panel
Connectivity / Interface
USB2.0 Hi-speed, 1000BASE-T/100BASE-TX/10BASE-T
Supported OS
Windows 11, Windows Server 2016,2019,2022,2025 Standard
Operating Environment Temperature
Operating temperature range: 41°–95°F (5°–35°C); Guaranteed print qualty is ensured between 59°- 86F(15°-30℃)
Operating Environment Humidity
10 – 90% RH (Non-Condensing) Guaranteed print qualty is ensured between 10-80%RH
Chemical Safety
TSCA, OSHA HCS
Power Consumption
53W (operating), 1.9W (sleep mode), 0.1W(OFF)
Electrical
AC 100-240V, 50/60Hz
Max. Operating Noise
55dB or less
Standby Noise
35dB or less
Warranty
1 Year Warranty including Printhead
Dimensions
22.5”(W) x 29.4”(D) x 17.2”(H) (572mm(W) x 746mm(D) x 436mm(H))
Weight
79.4 lbs. (36kg)
